Keys
NOTE: Your computer may look slightly different from the illustration in this section.
Component Description
(1) esc key Displays system information when pressed in combination with the
fn key.
(2) fn key Executes frequently used system functions when pressed in
combination with a function key or the esc key.
(3) Windows logo key Displays the Windows Start menu.
(4) Windows applications key Displays a shortcut menu for items beneath the pointer.
(5) Integrated numeric keypad keys Can be used like the keys on an external numeric keypad.
(6) Function keys Execute frequently used system functions when pressed in
combination with the fn key.
12 Chapter 2 External component identification

Table of Contents

Other manuals for HP EliteBook 8730w

Preview: Brochure & Specs
Brochure & Specs8 pages
Preview: Quickspecs
Quickspecs46 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8730w and is the answer not in the manual?

HP EliteBook 8730w Specifications

HP EliteBook 8530w Mobile Workstation

Processor and Chipset IconProcessor and Chipset
processorIntel Core Duo (up to 3.06 GHz, up to 6 MB L2 cache), Intel Core Quad-Core (up to 2.53 GHz, up to 12 MB L2 cache)
chipsetMobile Intel PM45 Express Chipset (Discrete)
Graphics IconGraphics
graphicsATI Mobility FireGL V5700 with 256MB of video memory, NVIDIA Quadro FX 770M with 512MB of video memory
Memory and Storage IconMemory and Storage
memoryDDR2 SDRAM, 800 MHz, two SODIMM slots supporting dual channel memory
maximum memoryup to 8, 192 GB
primary storageSATA II hard drives: 160/250 GB 5400 rpm, 160/250/320 GB 7200 rpm, 80 GB Solid State Drive (SSD)
Battery IconBattery
battery8-cell (73 WHr) Lithium-Ion battery
optional batteryHP Extended Life Battery (52 WHr), HP Ultra-Capacity Battery (95 WHr)
Display IconDisplay
display15.4-inch diagonal WSXGA+ WVA (1680 x 1050), 15.4-inch diagonal WUXGA WVA (1920 x 1200)
Ports & Interfaces IconPorts & Interfaces
usb ports4 USB 2.0
other portsRJ-11, RJ-45, headphone jack, microphone jack, docking, Smart AC adapter, VGA, secondary battery connector, 1394a, HDMI, eSATA
media card reader6-in-1

HP EliteBook 8730w Mobile Workstation

Processor and Chipset IconProcessor and Chipset
processorIntel Core Duo (up to 3.06 GHz, up to 6 MB L2 cache), Intel Core Quad-Core (up to 2.53 GHz, up to 12 MB L2 cache)
chipsetMobile Intel PM45 Express Chipset
Graphics IconGraphics
graphicsATI Mobility FireGL V5725 with 256 MB of video memory, NVIDIA Quadro FX 2700M with 512 MB of video memory, NVIDIA Quadro FX 3700M with 1 GB of video memory
Memory and Storage IconMemory and Storage
memoryDDR2 SDRAM, 800 MHz, two SODIMM slots supporting dual channel memory
maximum memoryup to 8, 192 GB
primary storageSATA II hard drives: 160/250 GB 5400 rpm, 160/250/320 GB 7200 rpm, 80 GB Solid State Drive (SSD)
Battery IconBattery
battery8-cell (73 WHr) Lithium-Ion battery
optional batteryHP Extended Life Battery (52 WHr), HP Ultra-Capacity Battery (95 WHr)
Display IconDisplay
display17-inch diagonal WSXGA+ WVA (1680 x 1050), 17-inch diagonal WUXGA WVA (1920 x 1200), 17-inch diagonal WUXGA WVA DreamColor (1920 x 1200)
Ports & Interfaces IconPorts & Interfaces
usb ports4 USB 2.0
other portsRJ-11, RJ-45, headphone jack, microphone jack, docking, Smart AC adapter, VGA, secondary battery connector, 1394a, HDMI, eSATA
media card reader6-in-1
