3. Remove the graphics card by sliding it away from the graphics card slot at an angle (3).
NOTE: The graphics card is designed with a notch to prevent incorrect installation.
NOTE: The thermal material must be thoroughly cleaned from the surfaces of the graphics card
and graphics card heat sink each time the graphics card heat sink is removed.
Reverse this procedure to install the graphics card.
Component replacement procedures 65
