Item Component Spare part number
(1) Display assembly: The display assembly is spared at the subcomponent level only. For more display assembly spare part
information, see Display assembly subcomponents on page 20.
(2) Keyboard (backlit; includes keyboard cable and pointing stick cable):
NOTE: For a list of keyboard country codes, see Keyboard on page 45.
785648-xx1
(3) Top cover
With ngerprint reader board 748352-001
Without ngerprint reader board 748353-001
Touchpad assembly (not illustrated) 822825-001
(4) Speakers (right and left; include cables) 702869-001
(5) AC power connector 702875-001
(6) Smart Card reader (includes cable) 769707-001
(7) Fan (includes cable) 702859-001
(8) System board (includes processor and replacement thermal material):
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-501: Windows 8.1 Standard operating system
xxxxxx-601: Windows 8.1 or Windows 10 operating system
●
Intel Core i7-4650U processor 769720-xxx
●
Intel Core i7-4600U processor 769719-xxx
●
Intel Core i5-4310U processor 769718-xxx
●
Intel Core i5-4210U processor 769717-xxx
Plastics Kit, includes: 702877-001
(9a) SD card insert
(9b) Hard drive cover
(10) Heat sink (includes replacement thermal material): 769708-001
(11) RTC battery 702853-001
(12) Fingerprint reader board (includes cable) 702845-001
(13) Base enclosure 702863-001
(14) Service cover 704441-001
Service cover, RCTO 713547-001
(15) Memory modules (PC3L-12800, 1600-MHz):
4-GB 691740-001
8-GB 693374-001
(16) WLAN module:
Intel Dual Band Wireless-AC 7260 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapter 710663-001
18 Chapter 3 Illustrated parts catalog
