HP EliteBook Folio 9480m User Manual

System board
NOTE: The system board spare part kit includes replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-501: Windows 8.1 Standard operating system
xxxxxx-601: Windows 8.1 or Windows 10 operating system
Description Spare part number
Intel Core i7-4650U processor 769720-xxx
Intel Core i7-4600U processor 769719-xxx
Intel Core i5-4310U processor 769718-xxx
Intel Core i5-4210U processor 769717-xxx
Before removing the system board, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 29), and then remove the following components:
a. Hard drive cover (see Hard drive cover on page 32)
b. Hard drive (see Hard drive/SSD drive on page 33)
c. Service cover (see Service cover on page 38)
d. Fan (see Fan on page 58)
e. Keyboard (see Keyboard on page 45)
f. Base enclosure (see Base enclosure on page 53)
NOTE: When replacing the system board, be sure that the following components are removed from the
defective system board and installed on the replacement system board:
●
SIM (see SIM on page 30, if applicable)
●
Memory module (see Memory module on page 39)
●
WWAN module (see WWAN module on page 41)
●
WLAN module (see WLAN module on page 43)
●
Heat sink (see Heat sink on page 62)
Remove the system board:
1. Disconnect the following cables:
●
(1): Right speaker cable
●
(2): Display panel
Component replacement procedures 59

HP EliteBook Folio 9480m Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-3667U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)	17 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	7200 RPM
SSD capacity	32 GB
HDD interface	SATA
Storage media	HDD+SSD
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	SD
Number of HDDs installed	1
Display surface	Matt
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	SRS Premium Sound PRO
Wi-Fi standards	Not supported
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Keyboard layout	-
Pointing device	Touchpad
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Operating system architecture	32-bit
Form factor	Clamshell
Product type	Laptop
Product color	Silver
Country of origin	China
Processor code	SR0N5
Processor ARK ID	64898
Processor package size	31 x 24 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	52 Wh
Battery life (max)	- h
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	231 mm
Width	338 mm
Height	18.9 mm
Weight	1610 g
