Hard drive cover
NOTE: The hard drive cover is available in the Plastics kit, spare part number 702877-001.
Description Spare part number
Plastics kit 702877-001
Before removing the hard drive cover, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 29).
Remove the hard drive cover:
1. Loosen the 2 captive hard drive cover screws (1).
2. Slide the hard drive cover away from the computer (2), and then lift the cover o the computer (3).
Reverse the removal procedures to install the hard drive cover.
32 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
