Display assembly components (panel, bezel, webcam, microphone)
All display assemblies include WLAN antenna transceivers and cables. WWAN models also include 2 WWAN
antenna transceivers and cables.
Full hinge-up displays are not spared.
This section describes removing components that do not require that you entirely remove the display
assembly from the computer. You can remove the display bezel, webcam/microphone module, and display
panel with the display assembly still attached to the computer.
To remove the remaining display components, including the display brackets, antennas, and enclosure, you
must remove the entire display assembly from the computer. See
Display assembly on page 67 for more
information about removing the remaining components.
Description Spare part number
Display panels
35.6-cm (14.0-in), HD+, anti-glare, LED 769722-001
35.6-cm (14.0-in), HD anti-glare, LED 769721-001
Display bezels
For use with models with a webcam 769705-001
For use with models without a webcam 769706-001
Webcam module with microphone 769710-001
Microphone module 702873-001
Before removing the display panel, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 29).
Remove the display assembly components:
1. Position the computer upright, with the front toward you.
2. Open the computer as far as possible.
3. If it is necessary to replace the display bezel or any of the display assembly subcomponents:
a. Flex the inside edges of the bottom edge (1), the left and right sides (2), and the top edge (3) of
the display bezel until the bezel disengages from the display enclosure.
50 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
