Rear panel components (ProDesk 400)
NOTE: Your computer model may look slightly dierent from the illustration in this section.
Item Icon Component Item Icon Component
1 Antenna cover 7 Serial port (black)
2 Thumbscrew 8 DisplayPort (optional)
NOTE: The DisplayPort is optional and
may be replaced with one of the following
ports: HDMI, VGA, or serial port.
3 Security cable slot 9 USB 3.x ports (2) (black)*
4 External antenna connector 10 USB 2.0 ports (2) (black)
5 Padlock loop 11 RJ-45 (network) jack
6 Dual-Mode DisplayPort (D++) 12 Power connector
*These USB ports allow for wake from S4/S5 hibernation system power states using the keyboard or mouse when enabled in BIOS.
4 Chapter 1 Product features
