7. To install a memory module, slide the SODIMM into the socket at approximately a 30° angle (1), then
press the SODIMM down (2) so that the latches lock it in place.
NOTE: A memory module can be installed in only one way. Match the notch on the module with the tab
on the memory socket.
8. Be sure that the cables around the system board (EMI) shield are out of the way and will not be pinched
by the EMI shield.
The computer automatically recognizes the additional memory when you turn on the computer.
Memory 51
