RJ-45 (network)
Pin Signal
1Transmit +
2Transmit -
3 Receive +
4Unused
5Unused
6 Receive -
7Unused
8Unused
Universal Serial Bus
Pin Signal
1 +5 VDC
2Data
3 Data +
4Ground
94 Chapter 8 Connector pin assignments ENWW
