HP ENVY 14

Top cover
NOTE: The top cover spare part kit includes the power button board and cable and TouchPad and
cable.
Description Spare part number
For use only on Beats Edition computer models 619402-001
For use only on standard computer models 608377-001
Before removing the top cover, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery cover and battery (see
Battery on page 37).
5. Remove the memory module/wireless module compartment cover (see
WLAN module
on page 45).
Remove the top cover:
1. Remove the eight Phillips PM2.5×7.0 screws that secure the top cover to the computer.
54 Chapter 4 Removal and replacement procedures ENWW
