Item Component Spare part number
Fix bracket, touch control board, and backlight cable (not illustrated)
●
HD models 774602-001
●
FHD models 774603-001
Mass storage devices
Component Spare part number
(1) Hard drive (does not include hard drive bracket, hard drive connector cable, or screws):
1-TB, 5400-rpm, 7.0-mm 762990-005
750-GB, 5400-rpm, 7.0-mm 752099-005
500-GB, 5400-rpm, 7.0-mm 778186-005
500-GB, 5400-rpm, 8 GB hybrid SSD, 7.0-mm 732000-005
Hard Drive Hardware Kit, includes: 768020-001
(2a) Hard drive bracket
(2b) Hard drive connector cable
(3) Solid-state drive
256-GB, TLC 777651-001
256-GB, MLC 777652-001
Solid-state Drive Hardware Kit, includes: 777653-001
(4a) Cable
(4b) Bracket
External DVD±RW Double-Layer with SuperMulti Drive (not illustrated) 747080-001
18 Chapter 3 Illustrated parts catalog
