3. Enter the default iLO IP address to access the server: http://192.168.0.120
4. Use the default user name and password found on the label attached to the top of the chassis to log in.
5. If prompted to do so, change the default iLO password according to your site-specific security requirements.
6. Select NetworkiLO Dedicated Network Port or NetworkShared Network Port.
7. Select the IPv4 tab.
8. On the IPv4 tab, enable DHCP or specify a static IP address, subnet mask, default gateway, and so on based on your
network environment.
9. Click Submit to save the network settings.
10. Connect the iLO port to a switch in the rack.
Connect to iLO and launch the Integrated Remote Console (IRC)
You connect to iLO through a web browser to launch the Java Integrated Remote Console (Java IRC), which you use to manage
each HPE SimpliVity 380 server remotely. You can also configure server settings.
Note: The Remote Console is compatible with different browsers and versions of Java. If you see errors while launching
or using the Remote Console, you might need to try a different browser or Java version. iLO also provides a .NET IRC
and an HPE iLO Mobile application for remote access.
Before you begin
Ensure you have configured the iLO port.
Procedure
1. Log in to any computer that can access the IP address for the iLO web interface.
2. Enter the iLO IP address into your browser.
For example: http://192.168.0.120
3. If you haven't changed the default settings, use the default user name and password found on the label attached to the
top of the chassis to log in. If you have changed the default settings, use the user name and password you configured.
4. Select Remote ConsoleRemote Console.
5. Click the appropriate launch link for your system.
Configure the iLO port for remote management 20
Documentation Feedback: doc-feedback-hpe-storage@hpe.com

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP HPE SimpliVity 380 Gen10 and is the answer not in the manual?

HP HPE SimpliVity 380 Gen10 Specifications

General IconGeneral
ProcessorIntel Xeon Scalable processors
Hypervisor SupportVMware vSphere, Microsoft Hyper-V
Network10GbE
Form Factor2U
Power SupplyRedundant Power Supplies
Operating SystemWindows Server
ManagementHPE OneView
MemoryUp to 6 TB DDR4 ECC Registered DIMMs
