Table 6: Pins on power connector
Voltage Pins
+12 VDC 81
GND 82
GND 83
+5 VDC 84
NOTE:
A nonstandard power connector is required for all HH FC drive).
Figure 4: Half-height FC power connections adapter
Configuration considerations 27
