Tape drive connector J42 Ethernet jack
Position 9 Ground
Position 10 Pin 4 Tx+
Position 11 Pin 5 Tx-
Position 12 Pin 7 Rx+
Position 13 Pin 8 Rx-
• Dual color supported on the Link Identification.
• The one-way DC resistance is 0.2 OHMS maximum on each connector.
• Source Voltage 3.3 V.
• Drive Current Capacity 12 mA.
Configuration considerations 29
