Full color calibrationA
It explains full color calibration.
● HP Indigo ElectroInk Silver is visually stable, therefore it is not necessary / not recommended to
perform Full Color Calibration (FCC).
● Full Color Calibration for Silver changes the BID electrode voltage only. (This can also be done
manually, as described in Performing Silver color adjustments on page 14).
NOTE: OD target for transparent media should be changed manually (see Color calibration
recommendations per substrate on page 31).
● Silver ink can be selected similarly to all other colors. Silver color calibration starts at the end of
other colors calibration. Silver ink will not fail calibration of other colors.
● When working with uncoated matte substrates (for example, wine label substrates), do not perform
full color calibration. Perform troubleshooting if issues exist (for example: image memory, flow
streaks, etc) – perform manual silver color calibration via Print Care (as described in Silver color
appearance and adjustments on page 11).
Color calibration recommendations per substrate
If full color calibration (FCC) is needed, refer to the table below for the Silver ink optical density (OD)
targets per substrate type.
Table A-1
FCC and Silver ink OD targets per substrate type
Substrate type Perform FCC?
OD target (M0) OD target (M0) OD target (M3)
SPM on press External X-Rite External eXact
Coated gloss white
(synthetic or paper)
Possible 0.07 0.09 1.1 ± 0.05
Coated semi matte
white (synthetic or
paper)
Possible 0.07 0.09 1.1 ± 0.05
Coated matte white Possible 0.07 0.09 1.1 ± 0.05
Uncoated / wine label No
Adjust manually through
Print Care
No target
It is recommended to use visual
inspection only
Transparent Possible 0.11
(change manually)
0.13 1.0 ± 0.05
See below for information about measuring the Silver ink optical density (OD).
