3-19
Using Identity Driven Manager
Configuring Network Resources
* Valid Friendly port names supported in IDM include: ftp, syslog, ldap,
http, imap4, imap3, nntp, pop2, pop3, smtp, ssl, telnet, bootpc, bootps,
ssh, dhcp, ntp, radius, rip, snmpsnmp-trap, tftp.
Note: If you are setting a resource to represent an application port such as "dhcp" or
"
smtp" or "http", you must make sure that you set the correct protocol, either
TCP or UDP. If you do not set the correct protocol, the rule will not operate as
intended at the switch or access point.
4. Click Ok to save the Network Resource definition and close the window.
All entries are saved immediately upon entry. This allows you to configure
several IDM features without closing and reopening the Configure Identity
Management window
Click
Cancel to close the window without saving your changes.
To Edit a Network Resource:
1. Click the
Network Resources node in the Identity Management Configuration
navigation tree to display the
Network Resources panel.
2. Click in the list to select the network resource to edit, then click the
Edit
Network Resource
toolbar icon to display the Define Network Resource win-
dow.
3. Edit the properties as needed. Refer to “Adding a Network Resource” on
the previous page for definitions.
4. Click Ok to save the Network Resource definition and close the window.
Protocol: Select UDP, TCP, or IP to identify the protocol used to filter access to
the resource. Protocol can be used alone or with an IP address and
port parameters to define the network resource access.
To use a custom protocol number for a network resource, check the
Enter protocol number checkbox and type the protocol number (0-137)
Port: Any port is selected by default, which means all ports associated to
the IP address are included in the network resource definition. To
specify a port for the network resource, click the Any port checkbox
to de-select it and enable the Port field. Enter the port number, or
friendly port name* used for the resource.
Table 3-2. IDM Network Resource parameters
