3-18
Using Identity Driven Manager
Configuring Network Resources
Adding a Network Resource
To define a Network Resource:
1. Click the
Network Resources node in the Identity Management Configuration
navigation tree to display the
Network Resources panel.
2. Click the
Add Network Resource toolbar icon to display the Define Network
Resource
window.
.
3. Define the properties for the network resource.
Name Name used to identify the network resource
Description Brief description of the network resource (optional)
Resource Attributes:
IP Address: To filter by device address, uncheck the Any Address checkbox and
type the IP address for the switch associated with the resource in the
IP Address field.
Use the Any address option if you will be filtering by Protocol and
application port only, and not by specific device or port.
Mask: The subnet mask for the IP Address (if used). Use the up/down buttons
[
▲, ▼] to set the mask number.
Table 3-2. IDM Network Resource parameters
