HP J9979A User Manual

2-1
2
Dashboard
You can use the Dashboard page to display and configure basic information about the system.
The Dashboard page displays basic information such as the configurable switch name and description, the IP
address for management access, and the software and operating system versions. This page also shows resource
usage statistics.
This page is displayed when you first log on or when you click Dashboard in the navigation pane.
Figure 2-1. Dashboard Page
If you update the name, location, or contact information, click Apply to save any changes for the current boot
session. The changes take effect immediately.

HP J9979A Specifications

General

Model	J9979A
Category	Switch
Layer	Layer 2
Jumbo Frame Support	Yes
Input Voltage	100 - 240 VAC
Uplink Ports	4
Management	Web, SNMP
Dimensions	44.25 x 30.0 x 4.4 cm
Weight	4.4 kg
Power Supply	Internal
Form Factor	Rack-mountable
Operating Temperature	0°C to 45°C
Operating Humidity	15% to 95% (non-condensing)
Ports	24 x 10/100/1000 ports
