HP J9979A User Manual

7-5
Link Layer Discovery Protocol (LLDP and LLDP-MED)
LLDP Local Device Summary
Displaying Port Details
To view additional LLDP information that the interface advertises, select the interface and click Details.
Figure 7-3. LLDP Local Device Information Page
In addition to the fields described in Table 7-3 on page 7-4, this page displays the following fields.
Table 7-4. LLDP Local Device Information Fields
Field Description
System Name The user-configured system name for the device. The system name is configured on the
Dashboard page.
System Description The device description which includes information about the product model and platform.
Management Address The address, such as an IP address, associated with the management interface of the device.
Management Address
Type
The protocol type or standard associated with the management address.
System IP The protocol type or standard associated with the management address.

HP J9979A Specifications

General

Model	J9979A
Category	Switch
Layer	Layer 2
Jumbo Frame Support	Yes
Input Voltage	100 - 240 VAC
Uplink Ports	4
Management	Web, SNMP
Dimensions	44.25 x 30.0 x 4.4 cm
Weight	4.4 kg
Power Supply	Internal
Form Factor	Rack-mountable
Operating Temperature	0°C to 45°C
Operating Humidity	15% to 95% (non-condensing)
Ports	24 x 10/100/1000 ports
