HP J9979A User Manual

7-11
Link Layer Discovery Protocol (LLDP and LLDP-MED)
LLDP-MED Local Device Summary
LLDP-MED Local Device Summary
Use the LLDP-MED Local Device Summary to view the information that is advertised by the switch interfaces
when they are enabled for LLDP-MED. To display this page, click LLDP-MED > Local Devices in the
navigation pane.
Figure 7-7. LLDP-MED Local Device Summary Page
Table 7-9. LLDP-MED Local Device Summary Fields
Field Description
Interface The trunk or port ID.
Port ID The interface identifier, which is its physical address.

HP J9979A Specifications

General

Model	J9979A
Category	Switch
Layer	Layer 2
Jumbo Frame Support	Yes
Input Voltage	100 - 240 VAC
Uplink Ports	4
Management	Web, SNMP
Dimensions	44.25 x 30.0 x 4.4 cm
Weight	4.4 kg
Power Supply	Internal
Form Factor	Rack-mountable
Operating Temperature	0°C to 45°C
Operating Humidity	15% to 95% (non-condensing)
Ports	24 x 10/100/1000 ports
