4-3
Switching Features
Port Configuration
Table 4-2. Edit Port Configuration Fields
Click Apply to save any changes for the current boot session. The changes take effect immediately and are
applied to each of the selected interfaces.
Port Summary Statistics
The Port Summary Statistics page displays statistics on packets transmitted and received on each port or trunk.
These statistics can be used to identify potential problems with the switch. The displayed values are the
accumulated totals since the last clear operation.
To display the Port Summary Statistics page, click Switching > Port Configuration in the navigation pane and
select the Statistics tab.
Figure 4-3. Port Summary Statistics Page
Field Description
Interface The interface or interfaces to be configured.
Admin Mode Select Enabled to make the port accessible on the network, or Disabled to prevent the port from
receiving or forwarding packets.
Physical Mode Select the duplex mode and transmission rate for the selected interface. The options may differ
depending on the port type and include options up to the port's maximum capability.
When Auto Negotiate (the default) is selected, the port negotiates an appropriate link speed with
its link partner.
Port
Description
Add an description of the interface (optional).
