HP J9981A User Manual

1-4
Getting Started
Getting Started With the Web Interface
Interface Layout and Features
Figure 1-2 shows the initial view.
Figure 1-2. Interface Layout and Features
Click on any topic in the navigation page to display related configuration options.
The Dashboard page displays when you first log on and when you click Dashboard in the navigation pane. See
“Dashboard” on page 2-1 for more information.
You can click the Setup Network link beneath Dashboard to display the Get Connected page, which you use
to set up a management connection to the switch. See “Get Connected” on page 3-1 for more information.
The graphical switch displays summary information for the switch LEDs and port status. For information on
this feature see “Graphical Switch” on page 1-5.
Navigation Pane
Graphical Switch
Common Links

HP J9981A Specifications

General

Management	Managed
PoE	No
Jumbo Frame Support	Yes
Form Factor	Rack-mountable
Model	J9981A
Layer	Layer 2
Weight	2.5 kg
MAC Address Table Size	16, 000 entries
Power Supply	Internal
Operating Temperature	0°C to 40°C
Ports	24 x 10/100/1000BASE-T ports 4 x SFP+ ports
Humidity	15% to 95% non-condensing
