HP J9981A User Manual

4-1
4
Switching Features
You can use the Switching pages to configure port operation and capabilities.
Port Configuration
You can use the Port Configuration pages to display port status, configure port settings, and view statistics on
packets transmitted on the port.
Port Status
The Port Status page displays the operational and administrative status of each port and enables port configu-
ration. To view this page, click Switching > Port Configuration in the navigation pane.
Figure 4-1. Port Status Page

HP J9981A Specifications

General

Management	Managed
PoE	No
Jumbo Frame Support	Yes
Form Factor	Rack-mountable
Model	J9981A
Layer	Layer 2
Weight	2.5 kg
MAC Address Table Size	16, 000 entries
Power Supply	Internal
Operating Temperature	0°C to 40°C
Ports	24 x 10/100/1000BASE-T ports 4 x SFP+ ports
Humidity	15% to 95% non-condensing
