HP J9981A User Manual

7-3
Link Layer Discovery Protocol (LLDP and LLDP-MED)
LLDP Global Configuration
To modify interface settings, select one or more interfaces and click Edit to display the Edit LLDP Interface
page. Or, click Edit All to modify settings on all interfaces.
Receive The LLDP receive mode on the interface. If the receive mode is enabled, the device can
receive LLDPDUs from other devices.
Notify Enable to have LLDP generate a log file entry.
Transmit Management
Information
The status of the LLDP remote data change notification on the interface. When enabled,
the interface sends notifications when a link partner device is added or removed.
Field Description

HP J9981A Specifications

General

Management	Managed
PoE	No
Jumbo Frame Support	Yes
Form Factor	Rack-mountable
Model	J9981A
Layer	Layer 2
Weight	2.5 kg
MAC Address Table Size	16, 000 entries
Power Supply	Internal
Operating Temperature	0°C to 40°C
Ports	24 x 10/100/1000BASE-T ports 4 x SFP+ ports
Humidity	15% to 95% non-condensing
