HP J9981A User Manual

7-13
Link Layer Discovery Protocol (LLDP and LLDP-MED)
LLDP-MED Remote Device Summary
Figure 7-9. LLDP-MED Remote Device Information Page
The following additional fields appear on the LLDP-MED Remote Device Information page:
Field Description
Supported
Capabilities
The supported capabilities that were received in the MED TLV on this interface.
Enabled
Capabilities
The supported capabilities on the remote device that are also enabled.
Device Class The MED Classification advertised by the TLV from the remote device.

HP J9981A Specifications

General

Management	Managed
PoE	No
Jumbo Frame Support	Yes
Form Factor	Rack-mountable
Model	J9981A
Layer	Layer 2
Weight	2.5 kg
MAC Address Table Size	16, 000 entries
Power Supply	Internal
Operating Temperature	0°C to 40°C
Ports	24 x 10/100/1000BASE-T ports 4 x SFP+ ports
Humidity	15% to 95% non-condensing
