12
3. Strip two screws from the rear cover，then move rear cover follow the below way
4. Strip four screws from the hinge
5. Remove the acetate tapes from the LVDS/ LED cable.
6. Pull out the LVDS/ LED cable to panel.
Remove the screws with
Screwdriver
Dismantle the rear cover first
from the two marked position
Remove the 8pin FFC from main
board then remove rear cover
To Next Page
