Table 3-1 Computer major components and their descriptions
Item Description Spare part number
(1) Display panel assembly
NOTE: Display panels are only available as spare parts at a subcomponent level.
not available as a spare
part
(2) Top cover/keyboard (includes cable)
NOTE: For a detailed list of keyboard country codes, see Keyboard/top cover on page 59.
With backlight L65224-001
No backlight L65225-001
(3) Touchpad (includes cable) L77252-001
(4) Fingerprint sensor assembly
NOTE: The ngerprint sensor cable is available in the Cable Kit as spare part number
L77263-001.
L77229-001
(5) Real-time clock (RTC) battery L02772-001
(6) USB board (includes cable)
NOTE: The USB board cable is available in the Cable Kit as spare part number L77263-001.
L44578-001
(7) Speaker assembly L44554-001
(8) Card reader board (includes cable)
NOTE: The card reader board cable is also available in the Cable Kit as spare part number
L77263-001.
L44579-001
(9) System board (includes integrated Intel Celeron 5205U processor and replacement thermal
material)
Non-Windows operating system L96032-001
Windows 10 IoT operating system L96032-301
(10) Heat sink (includes replacement thermal material) L44552-001
(11) Fan L44556-001
(12) WLAN module
Intel Dual Band Wireless-AC 9560 802.11ac 2 × 2 Wi-Fi + Bluetooth 5.0 Combo Adaptor (non-vPro) L22634-001
(13) Power connector cable L01048-001
(14) Memory module (DDR4-2400)
4 GB L10598-852
(15) M.2 solid-state drive
128 GB, SATA-3, TLC L85346-002
(16) Battery (3 cell, 45 Whr) L32656-005
(17) Bottom cover L44558-001
Computer major components 17
