Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing computer components.
Disassembly Sequence Chart
Section Description
# of Screws Removed
5.3 Preparing the Computer for
Disassembly
Battery 0
5.4 Hard Drive 2 loosened to remove the
hard drive cover
1 loosened to remove the
hard drive
4 to remove the hard drive
frame
5.5 Computer Feet 0
5.6 Bluetooth Module 0
5.7 External Memory Module 1 loosened to remove the
memory/Mini Card module
cover
5.8 Mini Card WLAN Module 2
Ä
To prevent an unresponsive system and the display of a
warning message, replace with only a Mini Card device
authorized for use in the computer by the governmental
agency that regulates wireless devices in your country. If
you replace the device and then receive a warning
message, remove the device to restore computer
functionality. Then contact Customer Care through the
Help and Support Center.
5.9 Optical Drive 1 to remove the optical drive
2 to remove the optical drive
bracket
