1–20 Maintenance and Service Guide
Product Description
The external components on the bottom of the computer are
shown below and described in Table 1-8.
Bottom Components
Table 1-8
Bottom Components
Item Component Function
1 Battery bay Holds the battery.
2 Battery release
latches (2)
Releases the battery from the battery bay.
3 Docking connector
(select computer
models only)
Connects the computer to an optional
docking device.
4 Accessory battery
connector (select
computer models only)
Connects an optional HP Ultra-Capacity
Battery or HP Extended Life Battery.
