Removal and Replacement Procedures
Maintenance and Service Guide 5–59
5.23 USB/Audio Board
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Memory/Mini Card module cover (Section 5.7)
c. Optical drive (Section 5.9)
d. Keyboard (Section 5.10)
e. Switch cover (Section 5.17)
f. Display assembly (Section 5.18)
g. Top cover (Section 5.19)
USB/Audio Board Spare Part Number Information
USB/audio board (includes audio board cable and USB board
cable)
413693-001
