HP nx6310 - Notebook PC User Manual

5–22 Maintenance and Service Guide
Removal and Replacement Procedures
7. If it is necessary to replace the optical drive bracket, remove
the two Phillips PM2.0×4.0 screws 1 that secure the bracket
to the optical drive.
8. Remove the optical drive bracket 2.
Removing the Optical Drive
Reverse the above procedure to reassemble and install an
optical drive.

HP nx6310 - Notebook PC Specifications

General

Graphics	Intel Graphics Media Accelerator 950
Networking	10/100/1000 Gigabit Ethernet
Memory	512 MB DDR2 SDRAM
Display	15.0" XGA (1024 x 768) TFT LCD
Optical Drive	DVD-ROM
Operating System	Windows XP Professional
Battery	6-cell Lithium Ion
Chipset	Intel 945GM
Wireless	802.11a/b/g
Ports	VGA, headphone, microphone, RJ-45, RJ-11
Storage	60 GB HDD
