A–6 Maintenance and Service Guide
Screw Listing
Phillips PM2.5×13.0 Screw Location
Table A-2
Phillips PM2.5×13.0 Spring-loaded Hard Drive Retention Screw
Color Qty. Length Thread
Head
Width
Silver 1 13.0 mm 2.5 mm 5.5 mm
Where used:
One screw that secures the hard drive to the computer (screw is captured on the
hard drive frame by a C-clip; documented in Section 5.4)
mm
