HP nx6310 - Notebook PC - Page 197

Screw Listing
Maintenance and Service Guide A–9
Torx8 T8M2.5×9.0 Screw Locations
Table A-4
Torx8 T8M2.5×9.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 24 9.0 mm 2.5 mm 4.0 mm
Where used:
2 screws that secure the keyboard to the computer (documented in
Section 5.10; left screw also secures optical drive)
mm
