HP OMEN 25 Maintenance And Service Guide

8
17
PCBA
1
18
PCBA
1
19
SCREW, I, CROSS, T2*3, Zn-Cc, ROHS
2
20
LENS, OMEN, HF
1
How to order parts
The HP authorized repair center can purchase the power board from HP.
Capacitors and connectors are available for purchase from the following EU distributors:
• Farnell: Farnell UK - Electronic Components Distributor
• RS Component: Capacitors | RS Components (rs-online.com)
• Digi-Key Component: Digi-Key Electronic United Kingdom
Connectors by manufacturer
Component description
Location
identifier
Component
distributor
Distributer part number
DisplayPort
CN401
Farnell
47272-0001
HDMI
CN301, CN302
Farnell
208658-1051
Headphone
CN101
Digi-Key
54-00177(Notes: the chassis
and rear cover need to be
modified to make the
connector opening larger)
USB upstream
CN701
Farnell
897-46-009-90-300000
USB A
CN702, CN703
Farnell
48405-0003
(Notes: the chassis and rear
cover need to be modified to
make the connector opening
larger)
DC jack
CN801
Digi-Key
PJ-096H
NOTE: The connector may need to be modified to meet functionality, regulatory and safety requirements if
it is not an exact match.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx.
NOTE: HP continually improves and changes product parts. For complete and current information about
supported parts for your computer, go to http://partsurfer.com, select your country or region, and then
follow the on-screen instructions.

HP OMEN 25 Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.283 x 0.283 mm
Screen shape	Flat
Display diagonal	24.5 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	302.6 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	543.7 mm
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Certification	CE; ICES; VCCI; FCC; C-Tick; CB; TUV-GS; ISO-9241-307; cTUVus; TUV LBL; CCC; CEL; BSMI; KCC; Australia MEPS; E-standby; PSB; ISC; Microsoft WHQL Certification (Windows 10, Windows 8.1 and Windows 7); SmartWay Transport Partnership - NA only
Product color	Black
Country of origin	China
Market positioning	Gaming
VESA mounting	-
Tilt angle range	-5 - 23 °
USB hub version	3.2 Gen 1 (3.1 Gen 1)
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
HP segment	Home
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	40 W
Annual energy consumption	35.3 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 70 %
Cables included	AC, HDMI, DisplayPort, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	227.5 mm
Width (with stand)	569 mm
Height (with stand)	407.9 mm
Weight (with stand)	4600 g
Depth (without stand)	62.8 mm
Height (without stand)	346.2 mm
Weight (without stand)	3550 g
