11
KP board separate step
4) Pull out all cables except the LVDS and unlock 4 screws fixed Main board and chassis then separate th
PCBA and chassis separate step
5) Unlock 4 screws fixed the hinge and chassis ,take out the small mylar then separate the hinge.
Chassis screw separate step
Connector repair
This procedure includes HDMI, DisplayPort, DC jack, headphone, USB upstream and USB connectors.
