HP OMEN Maintenance And Service Guide

Component Description
USB 3.x SuperSpeed port with HP Sleep and Charge
(2)
Connects a USB device, provides high-speed data transfer, and even
when the computer is o, charges most products such as a cell
phone, camera, activity tracker, or smartwatch.
USB Type-C power connector and Thunderbolt port
with HP Sleep and Charge
Connects an AC adapter that has a USB Type-C connector, supplying
power to the computer and, if needed, charging the computer
battery.
– and –
Connects and charges most USB devices that have a Type-C
connector, such as a cell phone, camera, activity tracker, or
smartwatch, and provides high-speed data transfer.
NOTE: Cables and/or adapters (purchased separately) may be
required.
– and –
Connects a display device that has a USB Type-C connector,
providing DisplayPort output.
NOTE: Your computer may also support a Thunderbolt docking
station.
Audio-out (headphone)/Audio-in (microphone)
combo jack
Connects optional powered stereo speakers, headphones, earbuds, a
headset, or a television audio cable. Also connects an optional
headset microphone. This jack does not support optional standalone
microphones.
WARNING! To reduce the risk of personal injury, adjust the volume
before putting on headphones, earbuds, or a headset. For additional
safety information, refer to the Regulatory, Safety, and
Environmental Notices.
To access this guide:
▲ Select the Start button, select HP Help and Support, and then
select HP Documentation.
NOTE: When a device is connected to the jack, the computer
speakers are disabled.
Audio-in (microphone) jack Connects an optional computer headset microphone, stereo array
microphone, or monaural microphone.
NOTE: The audio-in (microphone) jack does not support optional
combo devices, such as a headset.
NOTE: When devices are connected to the audio-out (headphone)/
Audio-in (microphone) combo jack and the audio-in (microphone)
jack at the same time, the audio-in jack has higher priority.
Memory card reader Reads optional memory cards that enable you to store, manage,
share, or access information.
To insert a card:
1. Hold the card label-side up, with connectors facing the
computer.
2. Insert the card into the memory card reader, and then press in
on the card until it is rmly seated.
To remove a card:
▲ Press in on the card, and then remove it from the memory card
reader.
8 Chapter 2 External component identication

HP OMEN Specifications

General

3D	-
Panel type	TN
Pixel pitch	0.283 x 0.283 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	24.5 \
Display technology	LED
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
On/off switch	Yes
Tilt angle range	-5 - 23 °
Certification	CE; ICES; VCCI; FCC; C-Tick; CB; TUV-GS; ISO-9241-307; cTUVus; TUV LBL; CCC; CEL; BSMI; KCC; Australia MEPS; E-standby; PSB; ISC; Microsoft WHQL Certification (Windows 10, Windows 8.1 and Windows 7); SmartWay Transport Partnership - NA only
Product color	Black
Country of origin	China
Market positioning	Gaming
USB hub version	3.2 Gen 1 (3.1 Gen 1)
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	40 W
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
HP segment	Home
Cables included	AC, HDMI, DisplayPort, USB

Weight and Dimensions

Depth (with stand)	227.5 mm
Height (with stand)	407.9 mm
Weight (with stand)	4600 g
Depth (without stand)	62.8 mm
Width (without stand)	569 mm
Height (without stand)	346.2 mm
Weight (without stand)	3550 g
