Technical white paper | HP P2000 G3 MSA
9
Note 1
Ownership of volumes is not visible to hosts. However, in SMU you can view volume ownership and change the owner of a
virtual disk and its volumes.
Note 2
Changing the ownership of a virtual disk should never be done with I/O in progress. I/O should be quiesced prior to changing
ownership.
In the following configuration, both hosts have redundant connections to all mapped volumes.
Figure 3. FC storage presentation during normal operation (high-availability, dual-controller, and direct attach with two hosts)
If a controller fails, the hosts maintain access to all of the volumes through the host ports on the surviving controller, as
shown in the Figure 4.

HP P2000 G3 MSA Specifications

General

Model	HP P2000 G3 MSA
Form Factor	2U
Drive Types	SAS, SATA
Controllers	Dual controllers
Host Interface	SAS, iSCSI, Fibre Channel
RAID Levels	0, 1, 5, 6, 10
Management	Web-based, CLI
Cache Memory	2 GB per controller
