HP P27 G5 User Manual

23
displayed on screen.
video signal cable between
the computer and monitor. Be
sure that the computer power
is off while connecting the
video cable.
Input Signal Out of
Range is displayed on
screen.
Video resolution, refresh rate, or both, are set
higher than the monitor supports.
Change the settings to a
supported setting.
The monitor does not
enter into a low-power
sleep state.
The monitor's power saving control is disabled.
Open the OSD menu and
select Power, select Auto-
Sleep Mode, and then set
auto-sleep to On.
“OSD Lockout” is
displayed
The monitor’s OSD lockout function is enabled.
Press and hold the Left
button for 10 seconds to
disable the OSD Lockout
function.
“Power Button
Lockout” is displayed.
The monitor's Power Button Lockout feature is
enabled.
Press and hold the Power
button for 10 seconds to
unlock the power button
function.
Monitor has trouble
waking from Sleep
mode
DisplayPower or USB Type-
C inputs: Set the DisplayPort
hot-plug detection to Always
Active.
Power mode monitors: Set
the hot-plug detection to
Always Active to switch the
monitor to Performance
mode.
Monitor is not
displaying the
preferred resolution or
refresh rate.
Multi-streaming USB Type-
C: Set the USB Type-C
configuration to USB 2.x.
Slow performance
from USB devices
connected to the USB
Type-A monitor
connectors
Set the USB Type-C
configuration to 3.x to enable
better performance for
integrated or connected USB
Type-A devices.

HP P27 G5 Specifications

General

Color depth	8 bit
Color gamut	72 %
Pixel pitch	0.31 x 0.31 mm
Screen shape	Flat
Pixel density	82 ppi
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	-
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 86 kHz
Viewable size, vertical	336.1 mm
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Viewable size, horizontal	597.9 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1400 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	35 W
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Product color	Black
Market positioning	Business
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Package depth	137 mm
Package width	685 mm
Package height	425 mm
Package weight	7640 g

Weight and Dimensions

Depth (with stand)	190.3 mm
Width (with stand)	611 mm
Height (with stand)	438.4 mm
Weight (with stand)	5080 g
Depth (without stand)	57.1 mm
Height (without stand)	365.5 mm
