Item Component Spare part number
Snow white finish 767250-001
Vibrant red finish 767253-001
(16) Power connector cable (includes bracket) 767246-001
(17) Battery 4 cell, 41 Whr, 2.8 Ah, Li-ion battery 756743-001
(18) Base enclosure (includes battery release latch mechanism, RJ-45 cover, and screws)
Aqua blue finish 780225-001
Natural silver finish 780226-001
Snow white finish 780224-001
Vibrant red finish 780227-001
(19) Service door
Aqua finish 767272-001
Natural silver finish 767273-001
Snow white finish 767258-001
Vibrant red finish 767274-001
16 Chapter 3 Illustrated parts catalog
