Hard drive
NOTE: The hard drive spare part kit does not include the hard drive rubber bracket, hard drive connector
cable, or screws. These components are included in the Hard Drive Hardware Kit, spare part number
767247-001.
Description Spare part number
500 GB, 5400 rpm, 9.5 mm 778188-005
750 GB, 5400 rpm, 9.5 mm 778190-005
1 TB, 5400 rpm, 9.5 mm 778192-005
1 TB, 5400 rpm + 8 GB NAND hybrid, 9.5 mm 731999-005
750 GB 5400 rpm + 8 GB NAND hybrid, 9.5 mm 732001-005
500 GB 5400 rpm + 8 GB NAND hybrid, 7 mm 732000-005
Before removing the hard drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 29), and then remove the following components:
a. Service door (see
Service door on page 30)
b. Optical drive (see
Optical drive on page 32)
c. Top cover (see
Top cover on page 39)
Remove the hard drive:
1. Disconnect the USB/audio cable (1) by flipping open the connector and lifting the cable. Lift up front of
the USB/audio board (2), and then remove the USB/audio board (3). The USB/audio board spare part
number is 767255-001.
Component replacement procedures 43
