Reverse this procedure to install the memory module.
Optical drive
NOTE: The optical drive spare part kit includes a bezel and bracket.
Description Spare part number
SuperMulti DVD±R/RW Double-Layer Drive
Aqua blue finish 767251-001
Natural silver finish 767252-001
Snow white finish 767250-001
Vibrant red finish 767253-001
Before removing the optical drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 29).
Remove the optical drive:
1. Using a small Phillips screwdriver, remove the Phillips M2.5×6.5 screw that secures the optical drive to
the computer (1).
2. Pull the tray (2) out from the front until the optical drive is completely removed from the computer.
If it is necessary to replace the optical drive bracket and bezel, position the optical drive with the rear panel
toward you.
1. Remove the two Phillips screws from the optical drive (1) and remove the bracket (2).
32 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
