Display assembly
This section describes removing the display assembly in its entirety and disassembling all the display
subcomponents.
If you only need to remove the display bezel, webcamera/microphone module, or display panel, you do not
need to remove the entire display assembly from the computer. See Display subcomponents (bezel, webcam,
panel) on page 34 for more information about removing the display subcomponents that do not require that
you remove the entire display assembly from the computer.
Description Spare part number
Raw display panel, 14.0 in (35.56 cm), high definition (HD), WLED, SVA BrightView flat display assembly 763566-001
Raw display panel, 14.0 in (35.56 cm), high definition (HD), WLED, SVA BrightView, touch, flat display
assembly
763567-001
Antennas 767237-001
Antennas, touch models 767238-001
Display bezel 767243-001
Display cable 767244-001
Display cable, touch models 767245-001
Display enclosure, aqua blue 763563-001
Display enclosure, natural silver 763564-001
Display enclosure, snow white 763562-001
Display enclosure, vibrant red 763565-001
Display enclosure, aqua blue, touch models 767240-001
Display enclosure, natural silver, touch models 763564-001
Display enclosure, snow white, touch models 767239-001
Display enclosure, vibrant red, touch models 763565-001
Hinge 767248-001
Hinge, touch models 767249-001
Webcamera/microphone module 762521-001
Webcamera/microphone module, touch models 762545-001
Before removing the display assembly, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 29), and then remove the following components:
Component replacement procedures 59
