Display subcomponents (bezel, webcamera, panel)
This section describes removing display subcomponents that do not require that you remove the entire
display assembly from the computer. You can remove the display bezel, webcam/microphone module, and
display panel while the display assembly is still attached to the computer.
To remove the remaining display subcomponents, you must remove the entire display assembly from the
computer. See
Display assembly on page 59 for more information about removing the display assembly in
its entirety.
Description Spare part number
Display bezel (includes screws) 767243-001
Raw display panel, 14 in (35.56 cm), WLED, HD, BrightView flat display panel 763566-001
Raw display panel, 14.0 in (35.56 cm), high definition (HD), WLED, SVA BrightView, touch, flat display panel 763567-001
Webcamera/microphone module 762521-001
Webcamera/microphone module, touch models 762545-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the display panel, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 29).
Remove the panel:
If it is necessary to replace the display bezel:
1. Remove the plastic screw covers (1) and the two Phillips M2.5×3.0 screws (2) that secure the display
bezel to the display assembly.
2. If it is necessary to replace the display bezel or any of the display assembly subcomponents:
a. Flex the inside edges of the top edge (3), the left and right sides (4), and the bottom edge (5) of
the display bezel until the bezel disengages from the display enclosure.
Component replacement procedures 35
