Spare part number Description
767253-001 Optical drive, DVD±RW Double-Layer SuperMulti Drive, vibrant red (includes bezel and bracket)
767254-001 Power button board (includes cable)
767255-001 USB/audio board (includes cable)
767256-001 TouchPad button board, ash silver (includes cable)
767257-001 TouchPad button board, ano silver (includes cable)
767258-001 Plastics Kit (includes service door, snow white)
767259-001 Plastics Kit (includes left and right rear corner covers)
767260-001 Rubber Kit (includes base rear rubber)
767261-001 Screw kit
767262-001 Speakers (include speaker cable)
767263-001 Top cover in black finish for use in the United States (includes keyboard and keyboard cable)
767263-161 Top cover in black finish for use in Latin America (includes keyboard and keyboard cable)
767263-DB1 Top cover in black finish for use in the United Kingdom and France (includes keyboard and keyboard
cable)
767264-001 Top cover in white finish for use in the United States (includes keyboard and keyboard cable)
767264-161 Top cover in white finish for use in Latin America (includes keyboard and keyboard cable)
767264-DB1 Top cover in white finish for use in the United Kingdom and France (includes keyboard and keyboard
cable)
767272-001 Plastics Kit (includes service door, aqua blue)
767273-001 Plastics Kit (includes service door, natural silver)
767274-001 Plastics Kit (includes service door, vibrant red)
778188-005 500 GB, 5400 rpm hard drive (SATA, 9.5 mm, does not include hard drive rubber bracket, hard drive
connector cable, or screws)
NOTE: The hard drive rubber bracket, hard drive connector cable, and screws are included in the Hard
Drive Hardware Kit, spare part number 767247-001.
778190-005 750 GB, 5400 rpm hard drive (SATA, 9.5 mm, does not include hard drive rubber bracket, hard drive
connector cable, or screws)
NOTE: The hard drive rubber bracket, hard drive connector cable, and screws are included in the Hard
Drive Hardware Kit, spare part number 767247-001.
778192-005 1 TB, 5400 rpm hard drive (SATA, 9.5 mm, does not include hard drive rubber bracket, hard drive
connector cable, or screws)
NOTE: The hard drive rubber bracket, hard drive connector cable, and screws are included in the Hard
Drive Hardware Kit, spare part number 767247-001.
780224-001 Base enclosure, snow white (includes battery release latch mechanism, RJ-45 cover, and screws)
780225-001 Base enclosure, aqua blue (includes battery release latch mechanism, RJ-45 cover, and screws)
780226-001 Base enclosure, natural silver (includes battery release latch mechanism, RJ-45 cover, and screws)
780227-001 Base enclosure, vibrant red (includes battery release latch mechanism, RJ-45 cover, and screws)
22 Chapter 3 Illustrated parts catalog
