Table 3-1 Computer major component descriptions and part numbers
Item Component Spare part number
(1) Display assembly
NOTE: Display assemblies are oered as spare parts only at a subcomponent level. For more
information, see Display assembly subcomponents on page 16.
not available as a
spare part
(2) Keyboard
NOTE: For a list of keyboard country codes, see Top cover with keyboard on page 51.
Not backlit, natural silver M52829-xx1
Backlit, natural silver M52830-xx1
Backlit, warm gold M52831-xx1
Backlit, ceramic white M52832-xx1
Backlit, pale rose gold M52833-xx1
(3) Touchpad
NOTE: The touchpad cable is available using spare part number M52811-001.
Natural silver M52799-001
Ceramic white M52800-001
Pale rose gold M52801-001
Warm gold M52802-001
(4) USB door
Natural silver M52790-001
Ceramic white M52791-001
Pale rose gold M52792-001
Warm gold M52793-001
(5) Audio board
NOTE: The audio board cable is available using spare part number M52812-001.
M52798-001
(6) Fan M52816-001
(7) Speakers (left and right) M52821-001
(8) System board (includes processor; for use in models with discrete graphics memory)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
AMD Ryzen7 5800U processor and 16 GB of system memory M52827-xx1
AMD Ryzen7 5800U processor and 8 GB of system memory M52828-xx1
AMD Ryzen5 5600U processor and 16 GB of system memory M52825-xx1
AMD Ryzen5 5600U processor and 8 GB of system memory M52826-xx1
(9) Battery (3 cell, 43 Whr) M24648-005
Computer major components 15
