2. Pull the drive away from the socket to remove it.
To install the solid-state drive, reverse the removal procedures.
NOTE: Solid-state drives are designed with a notch to prevent incorrect insertion.
Speakers
To remove the speakers, use this procedure and illustration.
Table 5-4 Speaker description and part number
Description Spare part number
Speaker Kit M52821-001
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 29).
2. Remove the bottom cover (see Bottom cover on page 29).
3. Disconnect the battery cable from the system board (see Battery on page 31).
Component replacement procedures 33
