8. Lift the memory module compartment cover (2) away from the computer.
9. If replacing a memory module, remove the existing memory module by:
a. Pulling away the retention clips (1) on each side of the memory module.
The memory module tilts up.
CAUTION: To prevent damage to the memory module, hold the memory module by the
edges only. Do not touch the components on the memory module.
b. Grasping the edge of the memory module (2), and gently pulling the module out of the memory
module slot.
To protect a memory module after removal, place it in an electrostatic-safe container.
10. Insert a new memory module by:
79
