Specifications and Regulatory Information
Hardware and Software Specifications
132 Reference Guide
I/O Ports Serial port: 9 pins (RS232), 16550 compatible
High-speed bidirectional parallel port: 25 pins, EPP/ECP capability
VGA port: 15 pins
PS/2: 6 pins, for keyboard, keypad or PS/2 mouse (Y adapter compatible)
Microphone-in, headphone-out jacks
Internal microphone
Docking port (on selected models): supports optional simple port replicator
One FIR port (on selected models)
Two USB ports
DC-in jack
Two Polk Audio stereo speakers
Composite TV-out
Controls Power switch
Lid switch
Reset off button
Sleep button
4 user-programmable One-Touch buttons
CD-Player on/off switch (on selected models)
CD-Player buttons (on selected models): Previous, Play/Pause, Stop/Eject,
Next, Volume-Up, Volume-Down
Pad Lock touch pad on/off button
Scroll up/down toggle
Status panel mode button (selected models only)
Status LEDs Caps/Num/Scroll lock LEDs (green)
Pad Lock touch pad on/off LED (amber)
Power status LED (dual color): power on green; standby amber
Battery charging LED: charging amber; fully charged green; abnormal red
HDD, FDD, CD-ROM activity LEDs (green)
LCD dot matrix display (with 2 backlight LEDs) (on selected models)
– When the unit is on, the display shows: power status, battery charging
status, date, or time (on selected models)
– When the unit is off and in CD-Player mode, the display shows, in addition:
sleep status, track number, and time elapsed (on selected models)
Backlight LEDs (green) for CD-Player buttons (on selected models)
CD-Player on/off LED (green) (on selected models)
2 LEDs on RJ-45 connector
Options 32/64/128MB PC-100 SODIMM: 3.3V, 144-pin, SDRAM
SPR (on selected models)
Mini-PCI modem, supporting Wake up on Ring# from D3 (cold) with AC-in
Mini-PCI modem/LAN combo, supporting Wake up on Ring# & PME# from D3
(cold) with AC-in
Mechanical Kensington lock
Continuously variable fan speed
