Specifications and Regulatory Information
Modem Reference Information
142 Reference Guide
Register Function (Ambit) Range/units Default
S33 XOFF character 0-255/ASCII 19 (13h)
S36 LAPM failure control 7
S37 Line connection speed 0
S38 Delay before forced hangup 0-255/s 20
S39 Flow control bit mapped options status 3
S40 General bit mapped options status 104 (68h)
S41 General bit mapped options status 195(C3h)
S46 Data compression control 138
S48 V.42 negotiation control 7
S82 LAPM break control 128 (40h)
S86 Call failure reason code 0-255
S91 PSTN transmit attenuation level 0-15/dBm 10 (country
dependent)
S92 Fax transmit attenuation level 0-15/dBm 10 (country
dependent)
S95 Result code messages control 0
Selected Result Codes (Ambit)
Code Meaning
0 OK
1 CONNECT
2 RING
3 NO CARRIER
4 ERROR
5 CONNECT 1200
6 NO DIAL TONE
7 BUSY
8 NO ANSWER
