HP Pavilion x2 User Manual

Spare part number Description
755530-D01 Power cord for use in Argentina
755530-D61 Power cord for use in India
756416-001 2-cell, 30-WHr, 4.15-AH battery (Tablet)
761233-001 Huawei Forester ME206 LTE with GPS M2
762179-005 500-GB, 5400-rpm, hybrid hard drive with 16 GB SSD
765921-001 Hinge connector
765922-001 Hard Drive Hardware Kit (includes cable, cover, and screws)
765928-001 USB/audio board
765929-001 HDMI board
765936-001 Light sensor board
765960-001 Webcam
765967-001 Tablet cover for use in models without a SIM module
765968-001 Tablet cover for use in models with a SIM module
765971-001 Bottom cover
765973-001 HDMI cable
765974-001 USB cable
765975-001 Power connector for use in dock
765979-001 Bracket Kit, includes bridge bracket and upper left and right brackets
765980-001 Hinge covers (front and rear)
765981-001 Hinge cavity
765982-001 Hinge bracket
765983-001 Card reader (includes cable)
765986-001 I/O board
765987-001 Touch screen board (includes cable)
765988-001 Audio/SD board for use in models without Bay Trail M processors (includes cable)
765989-001 Power button board (includes cable)
765990-001 Volume control board (includes cable)
765991-001 Home button board (includes cable)
765992-001 Docking board (includes cable)
765993-001 System board for use with non-Windows 8 models with an Intel Core i5-4202Y processor and 4 GB of system
memory (includes processor and replacement thermal material)
765993-501 System board for use with Windows 8 Standard models with an Intel Core i5-4202Y processor and 4 GB of
system memory (includes processor and replacement thermal material)
765994-001 System board for use with non-Windows 8 models with an Intel Core i3-4012Y processor and 4 GB of system
memory (includes replacement thermal material)
Sequential part number listing 19

HP Pavilion x2 Specifications

General

Bundled software	McAfee LiveSafe, Netflix
Operating system architecture	64-bit
Tjunction	90 °C
Processor cache	2 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom x5 Series
Processor socket	BGA 592
Processor codename	Cherry Trail
Processor frequency	1.44 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	1.92 GHz
PCI Express configurations	1x1
Thermal Design Power (TDP)	- W
Scenario Design Power (SDP)	2 W
Maximum number of PCI Express lanes	1
Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	White
Country of origin	China
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	On-board
Internal memory type	LPDDR3-SDRAM
Maximum internal memory	- GB
Storage media	eMMC
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	64 GB
Compatible memory cards	MicroSD (TransFlash)
Display diagonal	10.1 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Number of execution units	12
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	2 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	500 MHz
Docking connector	-
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Rear camera resolution (numeric)	5 MP
Audio decoders	DTS Studio Sound
Number of built-in speakers	2
Pointing device	Touchpad
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
AC adapter power	45 W
Battery capacity	32.5 Wh
Battery life (max)	10.5 h
Sustainability certificates	EPEAT Silver, ENERGY STAR
Processor code	SR2KT
Processor ARK ID	93361
Processor package size	17 x 17 mm
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
HP segment	Home
HP rear camera	HP Wide Vision 5MP
HP Software provided	HP Lounge

Weight and Dimensions

Depth	16.2 mm
Width	265 mm
Height	170 mm
Weight	1090 g
